PFA 1500x1500x0,8 mm natur
PFA combines excellent chemical and thermal properties with high purity and flexibility. This material is particularly suited for use in demanding environments where resistance to chemicals and high temperatures is crucial. The benefits of PFA include:
* Excellent chemical resistance
* High thermal stability
* Exceptional electrical properties
* Low coefficient of friction
* High purity
PFA is often used in chemical processing, semiconductor manufacturing, and medical equipment. If you need a material that can handle demanding conditions, PFA may be the right choice. Contact us if you want to know more about how PFA can be used in your application.
Technical Specifications
Color
Natural
Length
1500 mm
Material
Produktens basmaterial
Thickness
0.8 mm
Width
1500 mm
| Property | Value | Unit | Test standard |
|---|---|---|---|
| Density & Weight | |||
| Density | 2.15 | g/cm³ | DIN EN ISO 1183 |
| Tensile Properties | |||
| Tensile Strength | 15 | MPa | DIN EN ISO 527 |
| Modulus of elasticity (tensile) | 450 | MPa | DIN EN ISO 527 |
| Breakdown Voltage | 24 | MPa | DIN EN ISO 527 |
| Break Elongation | 250 | % | DIN EN ISO 527 |
| Hardness | |||
| Hardness Shore D | 55 | ° Shore D | DIN EN ISO 868 |
| Temperature Limits | |||
| Melting point | 300 | °C | ISO 3146 |
| Maximal operating temperature (short-term) | 260 | °C | |
| Maximum Operating Temperature | 260 | °C | |
| Minimum temperature | -190 | °C | |
| Heat deflection temperature (HDT/A) | 75 | °C | ISO 75 |
| Thermal Expansion | |||
| Thermal Expansion Coefficient | 1.4 | 10⁻⁴/K | ISO 11359-2 |
| Insulation Properties | |||
| Dielectric Strength | 33 | kV/mm | DIN IEC 60243-1 |
| Static spread | |||
| Surface Resistivity | ~10¹³ | Ω | DIN EN 61340 |
Identification
| Product name | Polytetrafluoreten (PTFE) / Teflon |
|---|---|
| Classification | not_classified |
| Supplier | ARC Gruppen AB // PlastShop.se |
| Chemical characterization | Polytetrafluoreten (PTFE), CAS 9002-84-0 |
| Physical/chemical hazards | Brandfarlig.. Vid överhettning (>300°C) kan ångor orsaka influensaliknande symtom (polymerångfeber). |
|---|---|
| Health hazards | Brandfarlig.. Vid överhettning (>300°C) kan ångor orsaka influensaliknande symtom (polymerångfeber). |
| Environmental hazards | Materialet är inte skadligt för miljön, men är inte biologiskt nedbrytbart. |
Physical properties
| Fysisk form | Fast, ogenomskinlig plast. Vit. |
|---|---|
| Färg | Fast, ogenomskinlig plast. Vit. |
| Odour | Lätt, produktspecifik |
| Melting point | 327°C |
|---|---|
| Auto-ignition | >530°C |
| Decomposition temp. | >400 °C |
| Solubility | Olöslig i alla kända lösningsmedel |
Handling and storage
| Handling | Vid bearbetning av halvfabrikatet bör spån sugas bort för att undvika halkskador. |
|---|---|
| Storage | Förvara inert produkt torrt och svalt. Håll lager- och arbetsutrymmen välventilerade. Håll borta från öppen låga, värmekälla eller antändning. På grund av risken för kollaps, stapla inte mer än två pallar ovanpå varandra. Pallar ska inte staplas ovanpå varandra längs gångar. |
Personal protection
| Gloves | Skyddshandskar vid kontakt med varmt material. |
|---|---|
| Eyes | Skyddsglasögon eller visir vid bearbetning. |
| Respiratory | Adekvat ventilering vid arbetsplatsen krävs. |
Stability and reactivity
| Förhållanden | Temperaturer över smältpunkten. |
|---|---|
| Materials to avoid | Starka oxidanter. |
| Decomposition products | Fluorväte (HF), perfluorisobuten (PFIB), koldioxid. |
Transport information
Inte klassificerad som farligt gods.
Legal specifications
Produkten kräver ingen varningsetikett i enlighet med EU-direktiv.
Resistant
Partially resistant
Not resistant
| Chemical | Concentration | Resist. |
|---|---|---|
| 1,4-Dioxane | 100 | |
| 2-Hydroxypropionic Acid | 90 | |
| Acetic Acid | 100 | |
| Acetone | 100 | |
| Ammonia | — | |
| Ammonium Chloride | — | |
| Amyl Alcohol | — | |
| Apple Juice | — | |
| Benzene | — | |
| Bleaching Solution | — | |
| Boric Acid | 100 | |
| Brake Fluid | — | |
| Butyl Acetate | — | |
| Calcium Chloride | — | |
| Carbon Disulfide | 100 | |
| Carbon Tetrachloride | — | |
| Chlorine (gas) | 100 | |
| Chlorobenzene | 100 | |
| Chloroform | — | |
| Citric Acid | 10 | |
| Cresol | — | |
| Cyclohexanone | 100 | |
| Cyclohexene | 100 | |
| Diesel Fuel | — | |
| Diethylene Oxide | — | |
| Ethyl Acetate | 100 | |
| Ethyl Alcohol | 96 | |
| Ethylene Chloride | 100 | |
| Food Oil | — | |
| Formaldehyde (aqueous) | 40 | |
| Formic Acid | 10 | |
| Frost Protection Agent | — | |
| Fuel, aromatic free | — | |
| Glycerine | 100 | |
| Glycol | 100 | |
| Heating Oil | — | |
| Heptane | 100 | |
| Hydrochloric Acid | 10 | |
| Hydrochloric Acid (concentrated) | — | |
| Hydrofluoric Acid | 40 | |
| Hydrogen Peroxide | 10 | |
| Hydrogen Sulfide (aqueous) | — | |
| Isopropyl Alcohol | 100 | |
| Linseed Oil | — | |
| Mercurochrome | — | |
| Methyl Alcohol | 100 | |
| Methyl Ethyl Ketone (MEK) | 100 | |
| Methylene Chloride | 100 | |
| Milk | — | |
| Mineral Oils (aromatic free) | — | |
| Nitric Acid | 10 | |
| Nitric Acid (50%) | 50 | |
| Nitrobenzene | — | |
| Oxalic Acid | — | |
| Ozone Gas | ≤ 0.5 ppm | |
| Paraffine Oil | 100 | |
| Perchloroethylene | — | |
| Petroleum | 100 | |
| Petroleum Ether | 100 | |
| Phenol (aqueous) | ca. 9 | |
| Phosphoric Acid | 50 | |
| Potassium Hydroxide liquor | 50 | |
| Premium Fuel | — | |
| Propyl Alcohol | — | |
| Pyridine | — | |
| Silicone Oil | — | |
| Sodium Carbonate (aqueous) | — | |
| Sodium Chloride (aqueous) | — | |
| Sodium Hydrogen Sulfite | — | |
| Sodium Hydroxide liquor | 15 | |
| Sodium Hydroxide liquor (60) | 60 | |
| Sodium Nitrate (aqueous) | — | |
| Sodium Thiosulfate | — | |
| Sulfuric Acid | 96 | |
| Tetrahydrofuran (THF) | 100 | |
| Toluene | 100 | |
| Transformer Oil | — | |
| Trichloroethylene | 100 | |
| Vinegar (standard) | 5 - 10 | |
| Water | — | |
| Xylene | — |
