PFA 1500x1500x6 mm natur
P2202786[P2202786] PFA 1500x1500x6 mm natur
Material
PFA
Format
Plate
Length
1500 mm
Width
1500 mm
Thickness
6 mm
Color
Natural
Egenskaper
Color
Natural
Length
1500 mm
Thickness
6 mm
Width
1500 mm
| Material | PFA |
| Format | Plate |
| Length | 1500 mm |
| Width | 1500 mm |
| Thickness | 6 mm |
| Color | Natural |
This content will be shared across all product pages.
Om produkten
PFA 1500x1500x6 mm natur
PFA combines excellent chemical and thermal properties with high purity and flexibility. This material is particularly suited for use in demanding environments where resistance to chemicals and high temperatures is crucial. The benefits of PFA include:
* Excellent chemical resistance
* High thermal stability
* Exceptional electrical properties
* Low coefficient of friction
* High purity
PFA is often used in chemical processing, semiconductor manufacturing, and medical equipment. If you need a material that can handle demanding conditions, PFA may be the right choice. Contact us if you want to know more about how PFA can be used in your application.
Tekniska specifikationer
Color
Natural
Length
1500 mm
Material
Produktens basmaterial
Thickness
6 mm
Width
1500 mm
Fördelar
Chemical Resistant
God motståndskraft mot kemikalier, syror och baser
Electrically Insulating
Hög volym- och ytresistivitet
Flame Retardant
Uppfyller brandklassning V-0 eller bättre
High Temperature Resistant
Behåller mekaniska egenskaper vid höga temperaturer
Low Friction
Låg friktionskoefficient, självsmörjande egenskaper
Low Temperature Resistant
Behåller mekaniska egenskaper vid låga temperaturer
Low Water Absorption
Minimal fuktupptagning, dimensionsstabil
Certifieringar
EU 10/2011
FDA
REACH
RoHS
Bearbetning
CNC Machining
Datorstödd bearbetning
Drilling
Håltagning med borr
Milling
Bearbetning med fräs
Sawing
Kapning med såg (band-, cirkelsåg)
Turning
Bearbetning i svarv
| Egenskap | Värde | Enhet | Teststandard |
|---|---|---|---|
| Density & Weight | |||
| Density | 2.15 | g/cm³ | DIN EN ISO 1183 |
| Tensile Properties | |||
| Tensile Strength | 15 | MPa | DIN EN ISO 527 |
| Modulus of elasticity (tensile) | 450 | MPa | DIN EN ISO 527 |
| Breakdown Voltage | 24 | MPa | DIN EN ISO 527 |
| Break Elongation | 250 | % | DIN EN ISO 527 |
| Hardness | |||
| Hardness Shore D | 55 | ° Shore D | DIN EN ISO 868 |
| Temperature Limits | |||
| Melting point | 300 | °C | ISO 3146 |
| Maximal operating temperature (short-term) | 260 | °C | |
| Maximum Operating Temperature | 260 | °C | |
| Minimum temperature | -190 | °C | |
| Heat deflection temperature (HDT/A) | 75 | °C | ISO 75 |
| Thermal Expansion | |||
| Thermal Expansion Coefficient | 1.4 | 10⁻⁴/K | ISO 11359-2 |
| Insulation Properties | |||
| Dielectric Strength | 33 | kV/mm | DIN IEC 60243-1 |
| Static spread | |||
| Surface Resistivity | ~10¹³ | Ω | DIN EN 61340 |
Identifiering
| Produktnamn | Polytetrafluoreten (PTFE) / Teflon |
|---|---|
| Klassificering | not_classified |
Fysikaliska egenskaper
| Utseende | Fast, ogenomskinlig plast. Vit. |
|---|---|
| Lukt | Lätt, produktspecifik |
| Smältpunkt | 327°C |
| Nedbrytningstemp. | >400 °C |
| Självantändning | >530°C |
| Löslighet | Olöslig i alla kända lösningsmedel |
Beständig
Delvis beständig
Ej beständig
| Kemikalie | Koncentration | Beständighet |
|---|---|---|
| 1,4-Dioxane | 100 | |
| 2-Hydroxypropionic Acid | 90 | |
| Acetic Acid | 100 | |
| Acetone | 100 | |
| Ammonia | - | |
| Ammonium Chloride | - | |
| Amyl Alcohol | - | |
| Apple Juice | - | |
| Benzene | - | |
| Bleaching Solution | - | |
| Boric Acid | 100 | |
| Brake Fluid | - | |
| Butyl Acetate | - | |
| Calcium Chloride | - | |
| Carbon Disulfide | 100 | |
| Carbon Tetrachloride | - | |
| Chlorine (gas) | 100 | |
| Chlorobenzene | 100 | |
| Chloroform | - | |
| Citric Acid | 10 | |
| Cresol | - | |
| Cyclohexanone | 100 | |
| Cyclohexene | 100 | |
| Diesel Fuel | - | |
| Diethylene Oxide | - | |
| Ethyl Acetate | 100 | |
| Ethyl Alcohol | 96 | |
| Ethylene Chloride | 100 | |
| Food Oil | - | |
| Formaldehyde (aqueous) | 40 | |
| Formic Acid | 10 | |
| Frost Protection Agent | - | |
| Fuel, aromatic free | - | |
| Glycerine | 100 | |
| Glycol | 100 | |
| Heating Oil | - | |
| Heptane | 100 | |
| Hydrochloric Acid | 10 | |
| Hydrochloric Acid (concentrated) | - | |
| Hydrofluoric Acid | 40 | |
| Hydrogen Peroxide | 10 | |
| Hydrogen Sulfide (aqueous) | - | |
| Isopropyl Alcohol | 100 | |
| Linseed Oil | - | |
| Mercurochrome | - | |
| Methyl Alcohol | 100 | |
| Methyl Ethyl Ketone (MEK) | 100 | |
| Methylene Chloride | 100 | |
| Milk | - | |
| Mineral Oils (aromatic free) | - | |
| Nitric Acid | 10 | |
| Nitric Acid (50%) | 50 | |
| Nitrobenzene | - | |
| Oxalic Acid | - | |
| Ozone Gas | ≤ 0.5 ppm | |
| Paraffine Oil | 100 | |
| Perchloroethylene | - | |
| Petroleum | 100 | |
| Petroleum Ether | 100 | |
| Phenol (aqueous) | ca. 9 | |
| Phosphoric Acid | 50 | |
| Potassium Hydroxide liquor | 50 | |
| Premium Fuel | - | |
| Propyl Alcohol | - | |
| Pyridine | - | |
| Silicone Oil | - | |
| Sodium Carbonate (aqueous) | - | |
| Sodium Chloride (aqueous) | - | |
| Sodium Hydrogen Sulfite | - | |
| Sodium Hydroxide liquor | 15 | |
| Sodium Hydroxide liquor (60) | 60 | |
| Sodium Nitrate (aqueous) | - | |
| Sodium Thiosulfate | - | |
| Sulfuric Acid | 96 | |
| Tetrahydrofuran (THF) | 100 | |
| Toluene | 100 | |
| Transformer Oil | - | |
| Trichloroethylene | 100 | |
| Vinegar (standard) | 5 - 10 | |
| Water | - | |
| Xylene | - |
Specifications
| Material | PFA |
| Format | Plate |
| Length | 1500 mm |
| Width | 1500 mm |
| Thickness | 6 mm |
| Color | Natural |
