ECTFE 3000x1500x2,3 mm natur
High chemical resistance and good thermal properties make this material an excellent choice for applications in the chemical industry or chemical processing. It also has good mechanical strength, stiffness, and impact resistance, which can be lacking in other fluoroplastics. The material can withstand temperatures of up to approximately 150°C and has high fire resistance with self-extinguishing properties. This material is suitable for components in the production of semiconductors due to its high purity. If you need a material that can handle tough chemicals and high temperatures, this may be the right choice. Contact us if you want to know more about how this material can be used in your application.
Technical Specifications
Color
Natural
Length
3000 mm
Material
Produktens basmaterial
Thickness
2.3 mm
Width
1500 mm
Chemical Resistant
God motståndskraft mot kemikalier, syror och baser
Electrically Insulating
Hög volym- och ytresistivitet
Flame Retardant
Uppfyller brandklassning V-0 eller bättre
High Temperature Resistant
Behåller mekaniska egenskaper vid höga temperaturer
Hydrolysis Resistant
Tål långvarig exponering för varmt vatten och ånga
Low Temperature Resistant
Behåller mekaniska egenskaper vid låga temperaturer
CNC Machining
Datorstödd bearbetning
Drilling
Håltagning med borr
Milling
Bearbetning med fräs
Sawing
Kapning med såg (band-, cirkelsåg)
Turning
Bearbetning i svarv
Welding
Sammanfogning genom svetsning (varmgas, spegel, ultraljud)
Identifiering
| Produktnamn | Polyvinylidenfluorid (PVDF) |
|---|---|
| Klassificering | not_classified |
| Tillverkare | ARC Gruppen AB // PlastShop.se |
Fysikaliska egenskaper
| Utseende | Fast, ogenomskinlig termoplast. Naturvit. |
|---|---|
| Lukt | Lätt, produktspecifik |
| Smältpunkt | 170-175°C |
| Nedbrytningstemp. | >350 °C |
| Självantändning | ca 420°C |
| Löslighet | Olöslig i vatten |
Beständig
Delvis beständig
Ej beständig
| Kemikalie | Koncentration | Beständighet |
|---|---|---|
| 1,4-Dioxane | 100 | |
| 2-Hydroxypropionic Acid | 90 | |
| Acetic Acid | 100 | |
| Acetone | 100 | |
| Ammonia | — | |
| Ammonium Chloride | — | |
| Amyl Alcohol | — | |
| Apple Juice | — | |
| Benzene | — | |
| Bleaching Solution | — | |
| Boric Acid | 100 | |
| Brake Fluid | — | |
| Butyl Acetate | — | |
| Calcium Chloride | — | |
| Carbon Disulfide | 100 | |
| Carbon Tetrachloride | — | |
| Chlorine (gas) | 100 | |
| Chlorobenzene | 100 | |
| Chloroform | — | |
| Citric Acid | 10 | |
| Cresol | — | |
| Cyclohexanone | 100 | |
| Cyclohexene | 100 | |
| Diesel Fuel | — | |
| Diethylene Oxide | — | |
| Ethyl Acetate | 100 | |
| Ethyl Alcohol | 96 | |
| Ethylene Chloride | 100 | |
| Food Oil | — | |
| Formaldehyde (aqueous) | 40 | |
| Formic Acid | 10 | |
| Frost Protection Agent | — | |
| Fuel, aromatic free | — | |
| Glycerine | 100 | |
| Glycol | 100 | |
| Heating Oil | — | |
| Heptane | 100 | |
| Hydrochloric Acid | 10 | |
| Hydrochloric Acid (concentrated) | — | |
| Hydrofluoric Acid | 40 | |
| Hydrogen Peroxide | 10 | |
| Hydrogen Sulfide (aqueous) | — | |
| Isopropyl Alcohol | 100 | |
| Linseed Oil | — | |
| Mercurochrome | — | |
| Methyl Alcohol | 100 | |
| Methyl Ethyl Ketone (MEK) | 100 | |
| Methylene Chloride | 100 | |
| Milk | — | |
| Mineral Oils (aromatic free) | — | |
| Nitric Acid | 10 | |
| Nitric Acid (50%) | 50 | |
| Nitrobenzene | — | |
| Oxalic Acid | — | |
| Ozone Gas | ≤ 0.5 ppm | |
| Paraffine Oil | 100 | |
| Perchloroethylene | — | |
| Petroleum | 100 | |
| Petroleum Ether | 100 | |
| Phenol (aqueous) | ca. 9 | |
| Phosphoric Acid | 50 | |
| Potassium Hydroxide liquor | 50 | |
| Premium Fuel | — | |
| Propyl Alcohol | — | |
| Pyridine | — | |
| Silicone Oil | — | |
| Sodium Carbonate (aqueous) | — | |
| Sodium Chloride (aqueous) | — | |
| Sodium Hydrogen Sulfite | — | |
| Sodium Hydroxide liquor | 15 | |
| Sodium Hydroxide liquor (60) | 60 | |
| Sodium Nitrate (aqueous) | — | |
| Sodium Thiosulfate | — | |
| Sulfuric Acid | 96 | |
| Tetrahydrofuran (THF) | 100 | |
| Toluene | 100 | |
| Transformer Oil | — | |
| Trichloroethylene | 100 | |
| Vinegar (standard) | 5 - 10 | |
| Water | — | |
| Xylene | — |
