  3. ECTFE 3000x1500x2,3 mm natural
EUR List Price €
ECTFE 3000x1500x2,3 mm natural

ECTFE 3000x1500x2,3 mm natural

https://utv.plastshop.se/web/image/product.template/23738/image_1920?unique=bbe33e4
SKU:
P2202721
(0.00 € / Units)
  • Material
  • Format
  • Length
  • Width
  • Thickness
  • Color

This combination does not exist.

 or    to get a price
Contact Us
Kategori: ECTFE plate

Share

ECTFE 3000x1500x2,3 mm natur High chemical resistance and good thermal properties make this material an excellent choice for applications in the chemical industry or chemical processing. It also has good mechanical strength, stiffness, and impact resistance, which can be lacking in other fluoroplastics. The material can withstand temperatures of up to approximately 150°C and has high fire resistance with self-extinguishing properties. This material is suitable for components in the production of semiconductors due to its high purity. If you need a material that can handle tough chemicals and high temperatures, this may be the right choice. Contact us if you want to know more about how this material can be used in your application.

Tekniska specifikationer

Density & Weight
Egenskap Värde Enhet Teststandard
Density 1.65 g/cm³ DIN EN ISO 1183-1
Tensile Properties
Egenskap Värde Enhet Teststandard
Tensile Strength 30.8 MPa DIN EN ISO 527
Modulus of elasticity (tensile) 1640 MPa DIN EN ISO 527
Break Elongation 50 % DIN EN ISO 527
Impact Resistance
Egenskap Värde Enhet Teststandard
Notched impact strength (Charpy) 100 kJ/m² DIN EN ISO 179-1eA
Hardness
Egenskap Värde Enhet Teststandard
Hardness Shore D 72.25 ° Shore D DIN EN ISO 868
Ball pressure hardness 56 MPa DIN EN ISO 2039-1
Temperature Limits
Egenskap Värde Enhet Teststandard
Maximal operating temperature (short-term) 156 °C
Maximum Operating Temperature 150 °C
Minimum temperature -40 °C
Vicat softening temperature (VST/B/50) 118 °C DIN EN ISO 306
Thermal Conductivity
Egenskap Värde Enhet Teststandard
Thermal Conductivity 0.15 W/(m·K) DIN 52612-1
Thermal Expansion
Egenskap Värde Enhet Teststandard
Thermal Expansion Coefficient 1 10⁻⁴/K ISO 11359-2
Insulation Properties
Egenskap Värde Enhet Teststandard
Dielectric Strength 23 kV/mm DIN IEC 60243-1
Static spread
Egenskap Värde Enhet Teststandard
Surface Resistivity 6666666667004.333 Ω DIN EN 61340
