PVC U 225x1000 mm svart
P2202138[P2202138] PVC U 225x1000 mm svart
Material
PVC
Format
Round bar
Length
1000 mm
Outer diameter
225 mm
Color
Black
| Material | PVC |
| Format | Round bar |
| Length | 1000 mm |
| Outer diameter | 225 mm |
| Color | Black |
This content will be shared across all product pages.
Om produkten
PVC U 225x1000 mm svart
High durability and chemical resistance are two of the most important properties of this material. It is resistant to moisture, chemicals, corrosion, and wear, and retains its properties even under stress and in demanding environments. This material is also highly resistant to many chemicals, making it suitable for use in industrial and chemical applications. It is an economical alternative compared to many other plastic materials. It is often used in plumbing systems and window profiles. If you need a material that can withstand tough conditions, this may be the right choice. Contact us if you want to know more about this material and how it can be used in your specific application.
Tekniska specifikationer
| Egenskap | Värde | Enhet | Teststandard |
|---|---|---|---|
| Density & Weight | |||
| Density | 1.53 | g/cm³ | ASTM D792 |
| Moisture Absorption | |||
| Water absorption to saturation | 0.5 | % | ASTM D570 |
| Water Absorption to Saturation | 0.5 | % | ASTM D570 |
| Tensile Properties | |||
| Tensile Strength | 48.8 | MPa | ASTM D638 |
| Modulus of elasticity (tensile) | 2669 | MPa | ASTM D638 |
| Breakdown Voltage | 40 | MPa | ISO 527 |
| Break Elongation | 14 | % | ISO 527 |
| Flexural Properties | |||
| Flexural Strength | 73.1 | MPa | ASTM D790 |
| Impact Resistance | |||
| Notched impact strength (Charpy) | 4 | kJ/m² | ISO 179 |
| Impact Resistance (Charpy) | 550 | kJ/m² | DIN EN ISO 8256 |
| Hardness | |||
| Hardness Shore D | 85 | ° Shore D | ASTM D2240 |
| Ball pressure hardness | 100 | MPa | ISO 2039 |
| Temperature Limits | |||
| Melting point | 189.2 | °C | ASTM D3418 |
| Maximal operating temperature (short-term) | 93.3 | °C | UL 746B |
| Maximum Operating Temperature | 60 | °C | |
| Minimum temperature | -15 | °C | UL 746B |
| Heat deflection temperature (HDT/A) | 106.7 | °C | ASTM D648 |
| Vicat softening temperature (VST/B/50) | 75 | °C | ISO 306 |
| Thermal Conductivity | |||
| Thermal Conductivity | 0.14 | W/(m·K) | ISO 22007-4 |
| Thermal Expansion | |||
| Thermal Expansion Coefficient | 1.03 | 10⁻⁴/K | ASTM D696 |
| Insulation Properties | |||
| Dielectric Strength | 40 | kV/mm | IEC 60243-1 |
| Volume Resistivity | 10¹⁵ | Ω·cm | DIN EN 62631-3-1 |
| Dielectric Constant (1 MHz) | 3.1 | - | IEC 60250 |
| Dielectric Constant (100 Hz) | 3.2 | - | IEC 60250 |
| Dielectric loss factor (1 MHz) | 0.0 | - | IEC 60250 |
| Static spread | |||
| Surface Resistivity | 10¹³ | Ω | DIN EN 62631-3-2 |
| Comparative Tracking Index (CTI) | 600 | V | IEC 60112 |
Color
Black
Length
1000 mm
Material
Produktens basmaterial
Outer Diameter
225 mm
Chemical Resistant
God motståndskraft mot kemikalier, syror och baser
Electrically Insulating
Hög volym- och ytresistivitet
Flame Retardant
Uppfyller brandklassning V-0 eller bättre
Food Safe
Godkänd för kontakt med livsmedel (FDA/EU 10/2011)
Recyclable
Materialet kan återvinnas
Weldable
Kan sammanfogas genom svetsning
Bonding
Sammanfogning med lim
CNC Machining
Datorstödd bearbetning
Drilling
Håltagning med borr
Milling
Bearbetning med fräs
Sawing
Kapning med såg (band-, cirkelsåg)
Turning
Bearbetning i svarv
Waterjet Cutting
Skärning med högtrycksvatten
Welding
Sammanfogning genom svetsning (varmgas, spegel, ultraljud)
Identifiering
| Produktnamn | Polyvinylklorid (PVC) |
|---|---|
| Klassificering | not_classified |
Fysikaliska egenskaper
| Utseende | Fast, ogenomskinlig termoplast. Grå, vit eller svart. |
|---|---|
| Lukt | Lätt, produktspecifik |
| Smältpunkt | 100-260°C (beroende på mjukgörare) |
| Nedbrytningstemp. | >200 °C (HCl-frigöring) |
| Självantändning | ca 455°C |
| Löslighet | Olöslig i vatten |
Beständig
Delvis bestandig
Ej bestandig
| Kemikalie | Koncentration | Beständighet |
|---|---|---|
| 1,4-Dioxane | 100% | |
| 2-Hydroxypropionic acid (lactic acid) | 90% | |
| Acetic acid | 100% | |
| Acetone | 100% | |
| Ammonia | conc. | |
| Ammonium chloride | - | |
| Amyl alcohol | - | |
| Apple juice | - | |
| Benzene | - | |
| Bleaching solution | 12.5 cl | |
| Boric acid | 100% | |
| Brake fluid | - | |
| Butyl acetate | - | |
| Calcium chloride | - | |
| Carbon disulphide | 100% | |
| Carbon tetrachloride | - | |
| Chlorine (gas) | 100% | |
| Chlorobenzene | 100% | |
| Chloroform | - | |
| Citric acid | 10% | |
| Cresol | - | |
| Cyclohexanone | 100% | |
| Cyclohexene | 100% | |
| Diesel | - | |
| Diethylene oxide | - | |
| Ethyl acetate | 100% | |
| Ethyl alcohol (ethanol) | 96% | |
| Ethylene chloride | 100% | |
| Food oil | - | |
| Formaldehyde (aqueous) | 40% | |
| Formic acid | 10% | |
| Frost protection agent | - | |
| Fuel (aromatic free) | - | |
| Fuel oil | - | |
| Glycerine | 100% | |
| Glycol | 100% | |
| Heptane | 100% | |
| Hydrochloric acid | 10% | |
| Hydrochloric acid (concentrated) | conc. | |
| Hydrofluoric acid | 40% | |
| Hydrogen peroxide | 10% | |
| Hydrogen sulfide (aqueous) | - | |
| Isopropyl alcohol | 100% | |
| Linseed oil | - | |
| Mercurochrome | - | |
| Methyl alcohol (methanol) | 100% | |
| Methyl ethyl ketone (MEK) | 100% | |
| Methylene chloride | 100% | |
| Milk | - | |
| Mineral oils (aromatic free) | - | |
| Nitric acid | 50% | |
| Nitric acid | 10% | |
| Nitrobenzene | - | |
| Oxalic acid | - | |
| Ozone (gas) | ≤ 0.5 ppm | |
| Paraffin oil | 100% | |
| Perchloroethylene | - | |
| Petroleum | 100% | |
| Petroleum ether | 100% | |
| Phenol (aqueous) | ca. 9% | |
| Phosphoric acid | 50% | |
| Potassium hydroxide solution | 50% | |
| Premium fuel | - | |
| Propyl alcohol | - | |
| Pyridine | - | |
| Silicone oil | - | |
| Sodium carbonate (aqueous) | - | |
| Sodium chloride (aqueous) | - | |
| Sodium hydrogen sulfite | - | |
| Sodium hydroxide solution (caustic soda) | 15% | |
| Sodium hydroxide solution (caustic soda) | 60% | |
| Sodium nitrate (aqueous) | - | |
| Sodium thiosulfate | - | |
| Sulphuric acid | 96% | |
| Tetrahydrofuran (THF) | 100% | |
| Toluene | 100% | |
| Transformer oil | - | |
| Trichloroethylene | 100% | |
| Vinegar (standard) | 5 - 10% | |
| Water | - | |
| Xylene | - |
Specifications
| Material | PVC |
| Format | Round bar |
| Length | 1000 mm |
| Outer diameter | 225 mm |
| Color | Black |
