Density & Weight
| Egenskap |
Värde |
Enhet |
Teststandard |
| Density |
0.91 |
g/cm³ |
ISO 1183 |
Moisture Absorption
| Egenskap |
Värde |
Enhet |
Teststandard |
| Water absorption to saturation |
0.2 |
% |
ISO 62 |
| Water Absorption to Saturation |
0.2 |
% |
ISO 62 |
Tensile Properties
| Egenskap |
Värde |
Enhet |
Teststandard |
| Tensile Strength |
36 |
MPa |
ISO 527 |
| Modulus of elasticity (tensile) |
1700 |
MPa |
ISO 527-2 |
| Breakdown Voltage |
30 |
MPa |
ISO 527 |
| Break Elongation |
8 |
% |
ISO 527-2 |
Flexural Properties
| Egenskap |
Värde |
Enhet |
Teststandard |
| Flexural Strength |
37 |
MPa |
DIN EN ISO 527-2 |
Impact Resistance
| Egenskap |
Värde |
Enhet |
Teststandard |
| Notched impact strength (Charpy) |
9 |
kJ/m² |
ISO 179/1eA |
| Impact Resistance (Charpy) |
7.7 |
kJ/m² |
ISO 179 |
Hardness
| Egenskap |
Värde |
Enhet |
Teststandard |
| Hardness Shore D |
72 |
° Shore D |
ISO 868 |
| Ball pressure hardness |
110 |
MPa |
ISO 2039 |
Temperature Limits
| Egenskap |
Värde |
Enhet |
Teststandard |
| Melting point |
161 |
°C |
DIN EN ISO 11357 |
| Maximal operating temperature (short-term) |
126.7273 |
°C |
UL746B |
| Maximum Operating Temperature |
79.569 |
°C |
|
| Minimum temperature |
-7.1667 |
°C |
|
| Heat deflection temperature (HDT/A) |
54 |
°C |
ISO 75 |
| Heat deflection temperature (HDT/B) |
90 |
°C |
ISO 75 |
| Vicat softening temperature (VST/B/50) |
50 |
°C |
ISO 306 |
Thermal Conductivity
| Egenskap |
Värde |
Enhet |
Teststandard |
| Thermal Conductivity |
0.27 |
W/(m·K) |
ISO 22007-4 |
Thermal Expansion
| Egenskap |
Värde |
Enhet |
Teststandard |
| Thermal Expansion Coefficient |
1.6 |
10⁻⁴/K |
ISO 11359-2 |
Insulation Properties
| Egenskap |
Värde |
Enhet |
Teststandard |
| Dielectric Strength |
40 |
kV/mm |
IEC 60243-1 |
| Volume Resistivity |
1014 |
Ω |
DIN EN 62631-3-1 |
| Dielectric Constant (1 MHz) |
2.371 |
- |
IEC 60250 |
| Dielectric loss factor (1 MHz) |
13.4119 |
- |
IEC 60250 |
| Dielectric loss factor (100 Hz) |
0.0002 |
- |
IEC 60250 |
Static spread
| Egenskap |
Värde |
Enhet |
Teststandard |
| Surface Resistivity |
1013 |
Ω |
IEC 60093 |
| Comparative Tracking Index (CTI) |
600 |
V |
IEC 60112 |
Fire Classification
| Egenskap |
Värde |
Enhet |
Teststandard |
| Flammability Classification (UL 94) |
60695 |
|
UL 94 |
A = Utmärkt, B = God, C = Begränsad, D = Ej rekommenderad
| Kemikalie |
Betyg |
Koncentration |
| 1,4-Dioxane |
B
|
100% |
| 2-Hydroxypropionic Acid |
A
|
90% |
| Acetic Acid |
A
|
100% |
| Acetone |
A
|
100% |
| Ammonia |
A
|
|
| Ammonium Chloride |
A
|
|
| Amyl Alcohol |
A
|
|
| Benzene |
B
|
|
| Bleaching Solution |
B
|
|
| Boric Acid |
A
|
100% |
| Brake Fluid |
A
|
|
| Butyl Acetate |
B
|
|
| Calcium Chloride |
A
|
|
| Carbon Disulfide |
B
|
100% |
| Carbon Tetrachloride |
D
|
|
| Chlorine (gas) |
D
|
100% |
| Chlorobenzene |
A
|
100% |
| Chloroform |
B
|
|
| Citric Acid |
A
|
10% |
| Cresol |
A
|
|
| Cyclohexanone |
A
|
100% |
| Cyclohexene |
A
|
100% |
| Diesel Fuel |
A
|
|
| Diethylene Oxide |
B
|
|
| Ethyl Acetate |
A
|
100% |
| Ethyl Alcohol |
A
|
96% |
| Ethylene Chloride |
A
|
100% |
| Food Oil |
A
|
|
| Formaldehyde, aqueous |
A
|
40% |
| Formic Acid |
A
|
10% |
| Frost Protection Agent |
A
|
|
| Fuel, aromatic free |
A
|
|
| Glycerin |
A
|
100% |
| Glycol |
A
|
100% |
| Heating Oil |
A
|
|
| Heptane |
B
|
100% |
| Hydrochloric Acid |
A
|
10% |
| Hydrochloric Acid (concentrated) |
A
|
|
| Hydrofluoric Acid |
A
|
40% |
| Hydrogen Peroxide |
A
|
10% |
| Hydrogen Sulfide, aqueous solution |
A
|
|
| Isopropyl Alcohol |
A
|
100% |
| Linseed Oil |
A
|
|
| Mercurochrome |
A
|
|
| Methyl Alcohol |
A
|
100% |
| Methyl Ethyl Ketone (MEK) |
A
|
100% |
| Methylene Chloride |
B
|
100% |
| Milk |
A
|
|
| Mineral Oils (aromatic free) |
A
|
|
| Nitric Acid |
A
|
10% |
