  3. PE Ultra HD 10x2000 mm dark blue
EUR List Price €
PE Ultra HD 10x2000 mm dark blue

PE Ultra HD 10x2000 mm dark blue

https://utv.plastshop.se/web/image/product.template/33365/image_1920?unique=6c31490
SKU:
P1400253
(0.00 € / Units)
  • Material
  • Format
  • Length
  • Outer diameter
  • Color

This combination does not exist.

 or    to get a price
Contact Us
Kategori: PE Round Bar

Share

PE Ultra HD 10x2000 mm mörkblå This material is characterized by its extremely high molecular weight, making it both tougher and harder. It has an outstanding wear resistance and is resistant to a range of chemicals, including acids, bases, and solvents. Its low friction results in a smooth and even surface, making it ideal for applications where sliding motions or contact with other surfaces are involved. This material is suitable for applications where the materials are subjected to intense friction or mechanical stress. Do you need help selecting the right material for your application? We'd be happy to help.

Tekniska specifikationer

Density & Weight
Egenskap Värde Enhet Teststandard
Density 0.9467 g/cm³ ISO 1183
Moisture Absorption
Egenskap Värde Enhet Teststandard
Water absorption to saturation 0.01 %
Water Absorption to Saturation 0.01 %
Tensile Properties
Egenskap Värde Enhet Teststandard
Tensile Strength 17 MPa ISO 527
Modulus of elasticity (tensile) 691.6667 MPa ISO 527
Break Elongation 316.6667 % ISO 527
Impact Resistance
Egenskap Värde Enhet Teststandard
Notched impact strength (Charpy) 80 kJ/m² ISO 11542-2
Impact Resistance (Charpy) 80 kJ/m² ISO 11542-2
Hardness
Egenskap Värde Enhet Teststandard
Hardness Shore D 60 ° Shore D shore D
Ball pressure hardness 35.6 MPa ISO 2039-1
Temperature Limits
Egenskap Värde Enhet Teststandard
Melting point 135 °C ISO 3146
Maximum Operating Temperature 10 °C
Minimum temperature -200 °C
Thermal Conductivity
Egenskap Värde Enhet Teststandard
Thermal Conductivity 0.4 W/(m·K) DIN 52612
Thermal Expansion
Egenskap Värde Enhet Teststandard
Thermal Expansion Coefficient 1.7 10⁻⁴/K DIN 53 752
Insulation Properties
Egenskap Värde Enhet Teststandard
Volume Resistivity 1012 Ω IEC 60093
Static spread
Egenskap Värde Enhet Teststandard
Surface Resistivity 1012 Ω IEC 60093
