PE Ultra HD 3000x1250x25 mm dark blå
P1400238[P1400238] PE Ultra HD 3000x1250x25 mm dark blå
Material
PE
Format
Plate
Length
3000 mm
Width
1250 mm
Thickness
25 mm
Color
Blue
Egenskaper
Color
Blue
Length
3000 mm
Thickness
25 mm
Width
1250 mm
| Material | PE |
| Format | Plate |
| Length | 3000 mm |
| Width | 1250 mm |
| Thickness | 25 mm |
| Color | Blue |
This content will be shared across all product pages.
Om produkten
PE Ultra HD 3000x1250x25 mm mörkblå
This plate is renowned for its exceptional properties and reliable performance, making it a popular and trustworthy solution for various industrial applications. The extremely high molecular weight renders the material both tougher and harder, resulting in a longer lifespan. The material boasts outstanding abrasion resistance, is resistant to chemicals, and has a very low friction coefficient. This makes it ideal for applications involving sliding motions or contact with other surfaces. It is suitable for applications where materials are subjected to intense friction or mechanical stress, such as in the machinery industry. Contact us if you want to know more about how this material can be used in your specific application.
Tekniska specifikationer
| Egenskap | Värde | Enhet | Teststandard |
|---|---|---|---|
| Density & Weight | |||
| Density | 0.9 | g/cm³ | ISO 1183 |
| Moisture Absorption | |||
| Water absorption to saturation | 0.01 | % | |
| Water Absorption to Saturation | 0.01 | % | |
| Tensile Properties | |||
| Tensile Strength | 17 | MPa | ISO 527 |
| Modulus of elasticity (tensile) | 691.7 | MPa | ISO 527 |
| Break Elongation | 316.7 | % | ISO 527 |
| Impact Resistance | |||
| Notched impact strength (Charpy) | 80 | kJ/m² | ISO 11542-2 |
| Impact Resistance (Charpy) | 80 | kJ/m² | ISO 11542-2 |
| Hardness | |||
| Hardness Shore D | 60 | ° Shore D | shore D |
| Ball pressure hardness | 35.6 | MPa | ISO 2039-1 |
| Temperature Limits | |||
| Melting point | 135 | °C | ISO 3146 |
| Maximum Operating Temperature | 10 | °C | |
| Minimum temperature | -200 | °C | |
| Thermal Conductivity | |||
| Thermal Conductivity | 0.4 | W/(m·K) | DIN 52612 |
| Thermal Expansion | |||
| Thermal Expansion Coefficient | 1.7 | 10⁻⁴/K | DIN 53 752 |
| Insulation Properties | |||
| Volume Resistivity | 10¹² | Ω | IEC 60093 |
| Static spread | |||
| Surface Resistivity | 10¹² | Ω | IEC 60093 |
Color
Blue
Length
3000 mm
Material
Produktens basmaterial
Thickness
25 mm
Width
1250 mm
Chemical Resistant
God motståndskraft mot kemikalier, syror och baser
Electrically Insulating
Hög volym- och ytresistivitet
Food Safe
Godkänd för kontakt med livsmedel (FDA/EU 10/2011)
High Wear Resistance
Utmärkt motstånd mot nötning och slitage
Low Temperature Resistant
Behåller mekaniska egenskaper vid låga temperaturer
Low Water Absorption
Minimal fuktupptagning, dimensionsstabil
Recyclable
Materialet kan återvinnas
Self-Lubricating
Kräver ingen extern smörjning
CNC Machining
Datorstödd bearbetning
Drilling
Håltagning med borr
Milling
Bearbetning med fräs
Sawing
Kapning med såg (band-, cirkelsåg)
Turning
Bearbetning i svarv
Waterjet Cutting
Skärning med högtrycksvatten
Identifiering
| Produktnamn | Polyeten (PE) |
|---|---|
| Klassificering | not_classified |
Fysikaliska egenskaper
| Utseende | Fast, halvgenomskinlig till ogenomskinlig termoplast. Vit till svart. |
|---|---|
| Lukt | Luktfri |
| Smältpunkt | 125-135°C (PE-HD), 130-145°C (PE-UHMW) |
| Nedbrytningstemp. | >350 °C |
| Självantändning | ca 350°C |
| Löslighet | Olöslig i vatten |
Beständig
Delvis bestandig
Ej bestandig
| Kemikalie | Koncentration | Beständighet |
|---|---|---|
| Acetic acid | 3% | |
| Calcium carbonate | - | |
| Ethanol | 10% | |
| Iron oxide | - | |
| Magnesium stearate | - | |
| Olive oil | - | |
| Silicon dioxide | - | |
| Titanium dioxide | - |
Specifications
| Material | PE |
| Format | Plate |
| Length | 3000 mm |
| Width | 1250 mm |
| Thickness | 25 mm |
| Color | Blue |
