PE-HD 2000x1000x1,5 mm svart
This material is characterized by its high strength and durability, featuring excellent tensile strength and compressive strength. It is resilient and can withstand mechanical stress, including impacts and flexures. Additionally, this material is resistant to a range of chemicals, making it suitable for use in demanding applications.
Uses can include the chemical industry or storage of corrosive substances.
Contact us if you would like to learn more about how this material can be used in your specific application.
Technical Specifications
Color
Black
Length
2000 mm
Material
Produktens basmaterial
Thickness
1.5 mm
Width
1000 mm
| Property | Value | Unit | Test standard |
|---|---|---|---|
| Density & Weight | |||
| Density | 0.96 | g/cm³ | ISO 1183 |
| Moisture Absorption | |||
| Water absorption to saturation | 0.01 | % | ISO 62 |
| Water Absorption to Saturation | 0.01 | % | ISO 62 |
| Tensile Properties | |||
| Tensile Strength | 20 | MPa | ISO 527 |
| Modulus of elasticity (tensile) | 1200 | MPa | ISO 527 |
| Breakdown Voltage | 13 | MPa | ISO 527 |
| Break Elongation | 200 | % | ISO 527 |
| Flexural Properties | |||
| Flexural Strength | 20 | MPa | ISO527-2 |
| Impact Resistance | |||
| Notched impact strength (Charpy) | 7.5 | kJ/m² | ISO 179/1eA |
| Impact Resistance (Charpy) | 15 | kJ/m² | ISO 179/1eU |
| Hardness | |||
| Hardness Shore D | 60 | ° Shore D | shore D |
| Ball pressure hardness | 50 | MPa | ISO 2039-1 |
| Temperature Limits | |||
| Melting point | 135 | °C | ISO 3146 |
| Maximal operating temperature (short-term) | 95 | °C | UL746B |
| Maximum Operating Temperature | 76 | °C | |
| Minimum temperature | -51 | °C | |
| Heat deflection temperature (HDT/A) | 45 | °C | ISO 75-2 |
| Heat deflection temperature (HDT/B) | 69 | °C | ISO 75 |
| Vicat softening temperature (VST/B/50) | 79 | °C | ISO 306 |
| Thermal Conductivity | |||
| Thermal Conductivity | 0.4 | W/(m·K) | DIN 52612 |
| Thermal Expansion | |||
| Thermal Expansion Coefficient | 2 | 10⁻⁴/K | ISO 11359 |
| Insulation Properties | |||
| Dielectric Strength | 45 | kV/mm | IEC 60243-1 |
| Volume Resistivity | 10¹² | Ω·cm | EN 61340-5-1 |
| Dielectric Constant (1 MHz) | 2.4 | - | IEC 60250 |
| Dielectric Constant (100 Hz) | 2.3 | - | IEC 60250 |
| Dielectric loss factor (1 MHz) | 0.0 | - | IEC 60250 |
| Dielectric loss factor (100 Hz) | 0.0 | - | IEC 60250 |
| Static spread | |||
| Surface Resistivity | 10¹³ | Ω | EN 61340-5-1 |
| Comparative Tracking Index (CTI) | 600 | V | IEC 60112 |
Identification
| Product name | Polyeten (PE) |
|---|---|
| Classification | not_classified |
| Supplier | ARC Gruppen AB // PlastShop.se |
| Chemical characterization | Polyeten (PE), CAS 9002-88-4 |
| Physical/chemical hazards | Brandfarlig vid höga temperaturer.. Damm kan orsaka mekanisk irritation vid bearbetning. |
|---|---|
| Health hazards | Brandfarlig vid höga temperaturer.. Damm kan orsaka mekanisk irritation vid bearbetning. |
| Environmental hazards | Materialet är inte skadligt för miljön, men är inte biologiskt nedbrytbart. |
Physical properties
| Fysisk form | Fast, halvgenomskinlig till ogenomskinlig termoplast. Vit till svart. |
|---|---|
| Färg | Fast, halvgenomskinlig till ogenomskinlig termoplast. Vit till svart. |
| Odour | Luktfri |
| Melting point | 125-135°C (PE-HD), 130-145°C (PE-UHMW) |
|---|---|
| Auto-ignition | ca 350°C |
| Decomposition temp. | >350 °C |
| Solubility | Olöslig i vatten |
Handling and storage
| Handling | Sug bort spån vid bearbetning. Undvik överhettning. |
|---|---|
| Storage | Förvara torrt och svalt. Håll borta från öppen låga. Välventilerade utrymmen. |
Personal protection
| Gloves | Skyddshandskar vid kontakt med varmt material. |
|---|---|
| Eyes | Skyddsglasögon vid bearbetning. |
| Respiratory | Adekvat ventilering vid bearbetning. |
Stability and reactivity
| Förhållanden | Temperaturer över smältpunkten. Undvik UV-exponering. |
|---|---|
| Materials to avoid | Starka oxidanter, syror. |
| Decomposition products | Koldioxid, kolmonoxid, vaxångor. |
Transport information
Inte klassificerad som farligt gods.
Legal specifications
Produkten kräver ingen varningsetikett enligt EU-direktiv.
Resistant
Partially resistant
Not resistant
| Chemical | Concentration | Resist. |
|---|---|---|
| 1,4-Dioxane | 100% | |
| 2-Hydroxypropionic acid (lactic acid) | 90% | |
| Acetaldehyde | — | |
| Acetic acid | 100% | |
| Acetic acid | 100% | |
| Acetic acid, aqueous | 70% | |
| Acetic anhydride | — | |
| Acetone | — | |
| Acetone | 100% | |
| Acronal dispersions | — | |
| Acrylonitrile | — | |
| Allyl acetate | — | |
| Allyl alcohol | 96% | |
| Allyl chloride | — | |
| Aluminium chloride, aqueous | any | |
| Aluminium chloride, solid | — | |
| Aluminium fluoride | Conc. | |
| Aluminium hydroxide | — | |
| Aluminium metaphosphate | — | |
| Aluminium sulphate, aqueous saturated | — | |
| Aluminium sulphate, solid | — | |
| Ammonia | concentrated | |
| Ammonia, gaseous | — | |
| Ammonia, liquid | — | |
| Ammonium chloride | — | |
| Amyl alcohol | — | |
| Aniline | any | |
| Anisole | — | |
| Aqua regia | — | |
| Beer | — | |
| Benzaldehyde, aqueous | any | |
| Benzene | — | |
| Benzene | technically grade | |
| Benzoic acid, aqueous | any | |
| Benzyl alcohol | — | |
| Bitumen | — | |
| Bleaching solution | 12.5 cl | |
| Boric acid | 100% | |
| Brake fluid | — | |
| Bromine, liquid | 100% | |
| Butanol, aqueous | any | |
| Butter | — | |
| Butyl acetate | — | |
| Calcium chloride | — | |
| Calcium hypochlorite, aqueous suspension | any | |
| Camphor | — | |
| Carbon disulphide | 100% | |
| Carbon disulphide | — | |
| Carbon tetrachloride | — | |
| Caustic soda (NaOH) | any | |
| Chlorine (gas) | 100% | |
| Chlorine, liquid | — | |
| Chloroacetic acid, aqueous | ≤85% | |
| Chlorobenzene | — | |
| Chlorobenzene | 100% | |
| Chloroform | technically grade | |
| Chloroform | — | |
| Chromosulphuric acid | — | |
| Cider | — | |
| Citric acid | 10% | |
| Citrus fruit juices | — | |
| Coconut oil | — | |
| Cod liver oil | — | |
| Cresol | 100% | |
| Cresol | — | |
| Cyclohexane | — | |
| Cyclohexanol | — | |
| Cyclohexanone | 100% | |
| Cyclohexanone | — | |
| Cyclohexene | 100% | |
| Detergents | usual | |
| Detergents | — | |
| Dibutyl ether | — | |
| Dibutyl phthalate | — | |
| Dichloroacetic acid | — | |
| Dichloroethane | — | |
| Diesel | — | |
| Diesel | — | |
| Diethylene oxide | — | |
| Diglycolic acid, aqueous | 30% | |
| Dimethyl formamide (DMF) | — | |
| Dimethylamine | — | |
| Dioxane | — | |
| Essential oils | — | |
| Ethyl acetate | — | |
| Ethyl acetate | 100% | |
| Ethyl alcohol (ethanol) | 96% | |
| Ethylene alcohol | 96% | |
| Ethylene chloride | 100% | |
| Ethylene chloride | — | |
| Ethylene diamine | — | |
| Ethylene glycol | — | |
| Ferric chloride, aqueous | any | |
| Ferric nitrate, aqueous saturated | — | |
| Ferric nitrate, aqueous saturated | — | |
| Ferric sulphate, aqueous saturated | — | |
| Ferric sulphate, aqueous saturated | — | |
| Ferrous (II) chloride, aqueous saturated | — | |
| Ferrous (II) sulfate, aqueous saturated | — | |
| Ferrous (III) chloride, aqueous saturated | — |
Showing first 100. Download complete list (PDF)
