  3. PE-1000 2000x1000x10 mm natur [P1200257] PE-1000 2000x1000x10 mm natur
List Price
PE-1000 2000x1000x10 mm natur

PE-1000 2000x1000x10 mm natur

P1200257

[P1200257] PE-1000 2000x1000x10 mm natur

https://utv.plastshop.se/web/image/product.template/25387/image_1920?unique=f58e450
Material PE Format Plate Length 2000 mm Width 1000 mm Thickness 10 mm Color Natural
Begär offert
(0.00 kr / Units)
  • Material
  • Format
  • Length
  • Width
  • Thickness
  • Color

This combination does not exist.

Egenskaper

Color Natural
Length 2000 mm
Thickness 10 mm
Width 1000 mm
Visa alla tekniska specifikationer
Material PE
Format Plate
Length 2000 mm
Width 1000 mm
Thickness 10 mm
Color Natural

This content will be shared across all product pages.

Contact Us

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share

Om produkten

PE-1000 2000x1000x10 mm natur High mechanical strength and impact resistance make HMWPE an excellent choice for demanding industrial applications. It also features good chemical resistance and low moisture absorption, making it suitable for use in environments where contact with chemicals is possible. HMWPE has excellent insulating properties, both thermal and electrical. It can be used as protective components and seals where impact and stress are common. If you need a material that can handle demanding conditions, HMWPE may be the right choice. Contact us if you want to know more about how HMWPE can be used in your specific application.

Tekniska specifikationer

Color
Natural
Length
2000 mm
Material

Produktens basmaterial

Thickness
10 mm
Width
1000 mm
Fördelar
Chemical Resistant

God motståndskraft mot kemikalier, syror och baser

Electrically Insulating

Hög volym- och ytresistivitet

Food Safe

Godkänd för kontakt med livsmedel (FDA/EU 10/2011)

High Wear Resistance

Utmärkt motstånd mot nötning och slitage

Low Temperature Resistant

Behåller mekaniska egenskaper vid låga temperaturer

Low Water Absorption

Minimal fuktupptagning, dimensionsstabil

Recyclable

Materialet kan återvinnas

Self-Lubricating

Kräver ingen extern smörjning

Certifieringar
EU 10/2011 FDA REACH RoHS
Bearbetning
CNC Machining

Datorstödd bearbetning

Drilling

Håltagning med borr

Milling

Bearbetning med fräs

Sawing

Kapning med såg (band-, cirkelsåg)

Turning

Bearbetning i svarv

Waterjet Cutting

Skärning med högtrycksvatten

Egenskap Värde Enhet Teststandard
Density & Weight
Density 0.95 g/cm³ ISO 1183
Moisture Absorption
Water absorption to saturation 0.01 %
Water Absorption to Saturation 0.01 % ISO 62
Tensile Properties
Tensile Strength 17 MPa ISO 527
Modulus of elasticity (tensile) 800 MPa DIN EN ISO 527-1/2
Breakdown Voltage 40 MPa ISO 527
Break Elongation 200 % ISO 527
Flexural Properties
Flexural Strength 17 MPa ISO 527-2
Impact Resistance
Notched impact strength (Charpy) 80 kJ/m² ISO 11542-2
Impact Resistance (Charpy) 80 kJ/m² DIN EN ISO 179-1/2
Hardness
Hardness Shore D 60 ° Shore D shore D
Ball pressure hardness 34 MPa ISO 2039-1
Compressive Properties
Creep Voltage at 1% Elongation 24 MPa ISO 178
Temperature Limits
Melting point 135 °C ISO 3146
Maximal operating temperature (short-term) 100 °C
Maximum Operating Temperature 64 °C
Minimum temperature -214 °C UL746B
Heat deflection temperature (HDT/A) 42 °C ISO 75
Heat deflection temperature (HDT/B) 65 °C ISO 75
Vicat softening temperature (VST/B/50) 79 °C DIN EN ISO 306
Thermal Conductivity
Thermal Conductivity 0.4 W/(m·K) DIN 52612
Thermal Expansion
Thermal Expansion Coefficient 2 10⁻⁴/K ISO 11359
Insulation Properties
Dielectric Strength 45 kV/mm IEC 60243-1
Volume Resistivity 1 Ω IEC 60093
Dielectric Constant (1 MHz) 2.3 - IEC 60250
Dielectric Constant (100 Hz) 2.55 - IEC 60250
Dielectric loss factor (1 MHz) 0.0 - IEC 60250
Dielectric loss factor (100 Hz) 0.0 - IEC 60250
Static spread
Surface Resistivity 10¹² Ω IEC 60093
Comparative Tracking Index (CTI) 600 V IEC 60112
Fire Classification
Flammability Classification (UL 94) 3 UL 94
Ladda ner tekniskt datablad (PDF)
Identifiering
ProduktnamnPolyeten (PE)
Klassificeringnot_classified
Fysikaliska egenskaper
UtseendeFast, halvgenomskinlig till ogenomskinlig termoplast. Vit till svart.
LuktLuktfri
Smältpunkt125-135°C (PE-HD), 130-145°C (PE-UHMW)
Nedbrytningstemp.>350 °C
Självantändningca 350°C
LöslighetOlöslig i vatten
Ladda ner komplett säkerhetsblad (PDF)
Beständig Delvis beständig Ej beständig
KemikalieKoncentrationBeständighet
1,4-Dioxane 100
2-Hydroxypropionic acid (lactic acid) 90
Acetic acid 100
Acetone 100
Ammonia -
Ammonium chloride -
Amyl alcohol -
Benzene -
Boric acid 100
Brake fluid -
Butyl acetate -
Calcium chloride -
Citric acid 10
Cresol -
Cyclohexanone 100
Cyclohexene 100
Diesel -
Ethyl acetate 100
Ethyl alcohol (ethanol) 96
Food oil -
Formaldehyde, aqueous 40
Formic acid 10
Frost protection agent -
Fuel oil -
Fuel, aromatic free -
Glycerine 100
Glycol 100
Heptane 100
Hydrochloric acid 10
Hydrochloric acid (concentrated) -
Hydrogen peroxide 10
Isopropyl alcohol 100
Linseed oil -
Mercurochrome -
Methyl alcohol (methanol) 100
Methylene chloride 100
Milk -
Mineral oils, aromatic free -
Nitric acid 50
Nitric acid 10
Nitrobenzene -
Oxalic acid -
Ozone (gas) ≤ 0.5 ppm
Paraffin oil 100
Perchloroethylene -
Petroleum ether 100
Phenol, aqueous ca. 9
Phosphoric acid 50
Potassium hydroxide solution 50
Premium fuel -
Propyl alcohol -
Silicone oil -
Sodium carbonate, aqueous -
Sodium chloride, aqueous -
Sodium hydrogen sulfite -
Sodium hydroxide solution (caustic soda) 60
Sodium hydroxide solution (caustic soda) 15
Sodium nitrate, aqueous -
Sodium thiosulfate -
Sulphuric acid 96
Transformer oil -
Vinegar, standard 5 - 10
Water -
Xylene -
Ladda ner kemisk beständighet (PDF)

Specifications

Material PE
Format Plate
Length 2000 mm
Width 1000 mm
Thickness 10 mm
Color Natural
