Density & Weight
| Egenskap |
Värde |
Enhet |
Teststandard |
| Density |
1.24 |
g/cm³ |
ISO 1183 |
Moisture Absorption
| Egenskap |
Värde |
Enhet |
Teststandard |
| Water absorption to saturation |
0.8 |
% |
ISO 62 |
| Water Absorption to Saturation |
0.3 |
% |
ISO 62 |
Tensile Properties
| Egenskap |
Värde |
Enhet |
Teststandard |
| Tensile Strength |
89 |
MPa |
ISO 527 |
| Modulus of elasticity (tensile) |
2680 |
MPa |
ISO 527 |
| Breakdown Voltage |
85 |
MPa |
DIN EN ISO 527 |
| Break Elongation |
10 |
% |
ISO 527 |
Impact Resistance
| Egenskap |
Värde |
Enhet |
Teststandard |
| Notched impact strength (Charpy) |
2 |
kJ/m² |
ISO 179-1/1eA |
| Impact Resistance (Charpy) |
170 |
kJ/m² |
ISO 179 |
Hardness
| Egenskap |
Värde |
Enhet |
Teststandard |
| Hardness Shore D |
87 |
° Shore D |
ISO 868 |
| Ball pressure hardness |
167 |
MPa |
ISO 2039 |
Temperature Limits
| Egenskap |
Värde |
Enhet |
Teststandard |
| Melting point |
188 |
°C |
ISO 3146 |
| Maximal operating temperature (short-term) |
160 |
°C |
UL746B |
| Heat deflection temperature (HDT/A) |
169 |
°C |
ISO 75 |
| Heat deflection temperature (HDT/B) |
181 |
°C |
ISO 75 |
Thermal Conductivity
| Egenskap |
Värde |
Enhet |
Teststandard |
| Thermal Conductivity |
0.25 |
W/(m·K) |
ISO 22007-4 |
Thermal Expansion
| Egenskap |
Värde |
Enhet |
Teststandard |
| Thermal Expansion Coefficient |
0.55 |
10⁻⁴/K |
ISO 11359 |
Insulation Properties
| Egenskap |
Värde |
Enhet |
Teststandard |
| Dielectric Strength |
42 |
kV/mm |
IEC 60243-1 |
| Volume Resistivity |
10000000000000 |
Ω·cm |
IEC 60093 |
| Dielectric Constant (1 MHz) |
3.1 |
- |
IEC 60250 |
| Dielectric loss factor (1 MHz) |
0.0055 |
- |
IEC 60250 |
Static spread
| Egenskap |
Värde |
Enhet |
Teststandard |
| Surface Resistivity |
10000000000000 |
Ω |
IEC 60093 |
| Comparative Tracking Index (CTI) |
125 |
V |
IEC 60112 |
A = Utmärkt, B = God, C = Begränsad, D = Ej rekommenderad
| Kemikalie |
Betyg |
Koncentration |
| Acetic Acid |
A
|
100% |
| Acetone |
D
|
100% |
| Ammonia |
B
|
|
| Benzene |
D
|
|
| Butyl Acetate |
A
|
|
| Calcium Chloride |
A
|
|
| Carbon Tetrachloride |
B
|
|
| Chlorobenzene |
D
|
100% |
| Chloroform |
D
|
|
| Citric Acid |
A
|
10% |
| Cyclohexene |
A
|
100% |
| Diesel Fuel |
A
|
|
| Diethylene Oxide |
A
|
|
| Ethyl Acetate |
D
|
100% |
| Ethyl Alcohol |
A
|
96% |
| Food Oil |
A
|
|
| Frost Protection Agent |
A
|
|
| Fuel (aromatic free) |
A
|
|
| Glycerin |
A
|
100% |
| Glycol |
A
|
100% |
| Heating Oil |
A
|
|
| Heptane |
A
|
100% |
| Hydrochloric Acid |
A
|
10% |
| Hydrochloric Acid (concentrated) |
B
|
|
| Hydrofluoric Acid |
B
|
40% |
| Hydrogen Peroxide |
A
|
10% |
| Isopropyl Alcohol |
A
|
100% |
| Methyl Alcohol |
A
|
100% |
| Methyl Ethyl Ketone (MEK) |
D
|
100% |
| Methylene Chloride |
D
|
100% |
| Milk |
A
|
|
| Mineral Oils (aromatic free) |
A
|
|
| Nitric Acid |
A
|
10% |
| Oxalic Acid |
A
|
|
| Perchloroethylene |
D
|
|
| Phosphoric Acid |
A
|
50% |
| Silicone Oil |
A
|
|
| Sodium Carbonate (aqueous) |
A
|
|
| Sodium Chloride (aqueous) |
A
|
|
| Sodium Hydroxide liquor |
A
|
15% |
| Sodium Hydroxide liquor (60%) |
A
|
60% |
| Sulfuric Acid |
D
|
96% |
| Toluene |
D
|
100% |
| Transformer Oil |
A
|
|
| Trichloroethylene |
D
|
100% |
| Vinegar (standard) |
A
|
5-10% |
| Water |
A
|
|
| Xylene |
D
|
|
