  3. PA6 C 1000x1220x12 mm natur [P1001776] PA6 C 1000x1220x12 mm natur
EUR List Price
PA6 C 1000x1220x12 mm natur

PA6 C 1000x1220x12 mm natur

P1001776

[P1001776] PA6 C 1000x1220x12 mm natur

https://utv.plastshop.se/web/image/product.template/23992/image_1920?unique=f58e450
Material PA Format Plate Length 1000 mm Width 1220 mm Thickness 12 mm Color Natural
Begär offert
(0.00 € / Units)
  • Material
  • Format
  • Length
  • Width
  • Thickness
  • Color

This combination does not exist.

Egenskaper

Color Natural
Length 1000 mm
Thickness 12 mm
Width 1220 mm
Visa alla tekniska specifikationer
Material PA
Format Plate
Length 1000 mm
Width 1220 mm
Thickness 12 mm
Color Natural

This content will be shared across all product pages.

Contact Us

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share

Om produkten

PA6 C 1000x1220x12 mm natur Flame-retardant properties make PA an ideal material for applications where fire safety is of utmost importance. It has high tensile strength, stiffness, and impact resistance, making it a strong and durable material choice. PA also offers good chemical resistance to a range of common chemicals and solvents. It is suitable for use in components and parts that require both mechanical strength and fire safety, such as the electrical and electronics industry, automotive industry, and construction sector. If you need help selecting the right material for your application, contact us.

Tekniska specifikationer

Color
Natural
Length
1000 mm
Material

Produktens basmaterial

Thickness
12 mm
Width
1220 mm
Fördelar
Dimensionally Stable

Låg krypning och minimal formförändring

Easy to Machine

Lätt att bearbeta med konventionella verktyg

High Impact Resistance

Utmärkt motstånd mot slag och stötar

High Stiffness

Hög elasticitetsmodul och formstabilitet

High Wear Resistance

Utmärkt motstånd mot nötning och slitage

Vibration Damping

God förmåga att absorbera vibrationer

Certifieringar
REACH RoHS
Bearbetning
CNC Machining

Datorstödd bearbetning

Drilling

Håltagning med borr

Milling

Bearbetning med fräs

Sawing

Kapning med såg (band-, cirkelsåg)

Threading

Skärning av gängor (invändig/utvändig)

Turning

Bearbetning i svarv

Egenskap Värde Enhet Teststandard
Density & Weight
Density 1.1 g/cm³ ISO 1183
Moisture Absorption
Water absorption to saturation 2.3 % ISO 62
Water Absorption to Saturation 6.5 % ISO 62
Tensile Properties
Tensile Strength 75 MPa ISO 527
Modulus of elasticity (tensile) 3500 MPa ISO 527-2
Break Elongation 25 % ISO 527-2
Flexural Properties
Flexural Strength 85 MPa ISO 527-2
Impact Resistance
Notched impact strength (Charpy) 3.5 kJ/m² ISO 179/1eA
Hardness
Ball pressure hardness 148.3 MPa ISO 2039-1
Temperature Limits
Melting point 220 °C ISO 3146
Maximal operating temperature (short-term) 170 °C
Maximum Operating Temperature 105 °C
Minimum temperature -30 °C
Heat deflection temperature (HDT/A) 80 °C ISO 75-2
Thermal Conductivity
Thermal Conductivity 0.29 W/(m·K) DIN 52612
Thermal Expansion
Thermal Expansion Coefficient 0.8 10⁻⁴/K ISO 11359
Insulation Properties
Dielectric Strength 25 kV/mm IEC 60243-1
Volume Resistivity 10¹⁴ Ω·cm IEC 60093
Dielectric Constant (1 MHz) 3.2 - IEC 60250
Dielectric Constant (100 Hz) 3.6 - IEC 60250
Dielectric loss factor (1 MHz) 0.0 - IEC 60250
Dielectric loss factor (100 Hz) 0.0 - IEC 60250
Static spread
Surface Resistivity 10¹³ Ω IEC 60093
Comparative Tracking Index (CTI) 600 V IEC 60112
Ladda ner tekniskt datablad (PDF)
Identifiering
ProduktnamnPolyamid (PA) / Nylon
Klassificeringnot_classified
Fysikaliska egenskaper
UtseendeFast, halvgenomskinlig till ogenomskinlig termoplast. Naturvit till svart.
LuktLätt, produktspecifik
Smältpunkt220-260°C (beroende på typ)
Nedbrytningstemp.>350 °C
Självantändningca 420°C
LöslighetOlöslig i vatten (absorberar fukt)
Ladda ner komplett säkerhetsblad (PDF)
Beständig Delvis beständig Ej beständig
KemikalieKoncentrationBeständighet
1,4-Dioxane 100
2-Hydroxypropionic Acid 90
Acetic Acid 100
Acetone 100
Ammonia conc.
Ammonium Chloride -
Amyl Alcohol -
Apple Juice -
Benzene -
Bleaching Solution 12.5 cl
Boric Acid 100
Brake Fluid -
Butyl Acetate -
Calcium Chloride -
Carbon Disulfide 100
Carbon Tetrachloride -
Chlorine (gas) 100
Chlorobenzene 100
Chloroform -
Citric Acid 10
Cresol -
Cyclohexanone 100
Cyclohexene 100
Diesel Fuel -
Diethylene Oxide -
Ethyl Acetate 100
Ethyl Alcohol 96
Ethylene Chloride 100
Food Oil -
Formaldehyde (aqueous) 40
Formic Acid 10
Frost Protection Agent -
Fuel (aromatic free) -
Glycerine 100
Glycol 100
Heating Oil -
Heptane 100
Hydrochloric Acid 10
Hydrochloric Acid (concentrated) conc.
Hydrofluoric Acid 40
Hydrogen Peroxide 10
Hydrogen Sulfide (aqueous) -
Isopropyl Alcohol 100
Linseed Oil -
Mercurochrome -
Methyl Alcohol 100
Methyl Ethyl Ketone (MEK) 100
Methylene Chloride 100
Milk -
Mineral Oils (aromatic free) -
Nitric Acid 10
Nitric Acid 50
Nitrobenzene -
Oxalic Acid -
Ozone Gas ≤ 0.5 ppm
Paraffine Oil 100
Perchloroethylene -
Petroleum 100
Petroleum Ether 100
Phenol (aqueous) ca. 9
Phosphoric Acid 50
Potassium Hydroxide liquor 50
Premium Fuel -
Propyl Alcohol -
Pyridine -
Silicone Oil -
Sodium Carbonate (aqueous) -
Sodium Chloride (aqueous) -
Sodium Hydrogen Sulfite -
Sodium Hydroxide liquor 60
Sodium Hydroxide liquor 15
Sodium Nitrate (aqueous) -
Sodium Thiosulfate -
Sulfuric Acid 96
Tetrahydrofuran (THF) 100
Toluene 100
Transformer Oil -
Trichloroethylene 100
Vinegar (standard) 5 - 10
Water -
Xylene -
Ladda ner kemisk beständighet (PDF)

Specifications

Material PA
Format Plate
Length 1000 mm
Width 1220 mm
Thickness 12 mm
Color Natural
