Density & Weight
| Egenskap |
Värde |
Enhet |
Teststandard |
| Density |
1.05 |
g/cm³ |
ISO 1183 |
Moisture Absorption
| Egenskap |
Värde |
Enhet |
Teststandard |
| Water absorption to saturation |
0.2 |
% |
ISO 62 |
| Water Absorption to Saturation |
1 |
% |
ISO 62 |
Tensile Properties
| Egenskap |
Värde |
Enhet |
Teststandard |
| Tensile Strength |
37 |
MPa |
ISO 527-2 |
| Modulus of elasticity (tensile) |
2600 |
MPa |
ISO 527-2 |
| Breakdown Voltage |
36.5 |
MPa |
ISO 527-2 |
| Break Elongation |
5 |
% |
ISO 527-2 |
Flexural Properties
| Egenskap |
Värde |
Enhet |
Teststandard |
| Flexural Strength |
2500 |
MPa |
ISO 178 |
Impact Resistance
| Egenskap |
Värde |
Enhet |
Teststandard |
| Notched impact strength (Charpy) |
25 |
kJ/m² |
ISO 179/1eA |
| Impact Resistance (Charpy) |
170 |
kJ/m² |
ISO 179/1eU |
Hardness
| Egenskap |
Värde |
Enhet |
Teststandard |
| Hardness Shore D |
70 |
° Shore D |
ISO 868 |
| Rockwell hardness |
80 |
R-scale |
DIN EN ISO 2039-2 |
| Ball pressure hardness |
98 |
MPa |
ISO 2039-1 |
Temperature Limits
| Egenskap |
Värde |
Enhet |
Teststandard |
| Melting point |
235 |
°C |
ISO 3146 |
| Maximal operating temperature (short-term) |
92.7273 |
°C |
UL746B |
| Maximum Operating Temperature |
82.5 |
°C |
|
| Heat deflection temperature (HDT/A) |
80 |
°C |
ISO 75-2 |
| Heat deflection temperature (HDT/B) |
100 |
°C |
ISO 75-2 |
| Vicat softening temperature (VST/B/50) |
101 |
°C |
ISO 306 |
Thermal Conductivity
| Egenskap |
Värde |
Enhet |
Teststandard |
| Thermal Conductivity |
0.2 |
W/(m·K) |
DIN 52612 |
Thermal Expansion
| Egenskap |
Värde |
Enhet |
Teststandard |
| Thermal Expansion Coefficient |
0.8 |
10⁻⁴/K |
DIN 11359 |
Insulation Properties
| Egenskap |
Värde |
Enhet |
Teststandard |
| Dielectric Strength |
18 |
kV/mm |
IEC 60243-1 |
| Volume Resistivity |
101500 |
Ω·cm |
IEC 60093 |
| Dielectric Constant (1 MHz) |
2.6 |
- |
IEC 60250 |
| Dielectric loss factor (1 MHz) |
0.008 |
- |
IEC 60250 |
Static spread
| Egenskap |
Värde |
Enhet |
Teststandard |
| Surface Resistivity |
1015 |
Ω |
IEC 60093 |
| Comparative Tracking Index (CTI) |
600 |
V |
IEC 60112 |
A = Utmärkt, B = God, C = Begränsad, D = Ej rekommenderad
| Kemikalie |
Betyg |
Koncentration |
| 1,4-Dioxane |
D
|
100% |
| 2-Hydroxypropionic Acid |
A
|
90% |
| Acetic Acid |
D
|
100% |
| Acetone |
D
|
100% |
| Ammonia |
A
|
|
| Ammonium Chloride |
A
|
|
| Amyl Alcohol |
A
|
|
| Apple Juice |
A
|
|
| Aqueous Formaldehyde |
A
|
40% |
| Aqueous Hydrogen Sulfide |
A
|
|
| Aqueous Phenol |
B
|
9% |
| Aqueous Sodium Carbonate |
A
|
|
| Aqueous Sodium Chloride |
A
|
|
| Aqueous Sodium Nitrate |
A
|
|
| Aromatic-free Fuel |
A
|
|
| Benzene |
D
|
|
| Brake Fluid |
D
|
|
| Butyl Acetate |
D
|
|
| Calcium Chloride |
A
|
|
| Carbon Disulfide |
D
|
100% |
| Carbon Tetrachloride |
D
|
|
| Chlorine gas |
D
|
100% |
| Chlorobenzene |
D
|
100% |
| Chloroform |
D
|
|
| Citric Acid |
A
|
10% |
| Cresol |
D
|
|
| Cyclohexanone |
D
|
100% |
| Cyclohexene |
A
|
100% |
| Diesel Fuel |
A
|
|
| Ethyl Acetate |
D
|
100% |
| Ethyl Alcohol |
D
|
96% |
| Ethylene Chloride |
D
|
100% |
| Food Oil |
A
|
|
| Formic Acid |
A
|
10% |
| Frost Protection Agent |
A
|
|
| Glycerin |
A
|
100% |
| Glycol |
A
|
100% |
| Heating Oil |
A
|
|
| Heptane |
A
|
100% |
| Hydrochloric Acid |
A
|
10% |
| Hydrochloric Acid (concentrated) |
A
|
|
| Hydrofluoric Acid |
B
|
40% |
| Hydrogen Peroxide |
A
|
10% |
| Isopropyl Alcohol |
B
|
100% |
| Linseed Oil |
A
|
|
| Mercurochrome |
B
|
|
| Methyl Alcohol |
D
|
100% |
| Methyl Ethyl Ketone (MEK) |
D
|
100% |
| Methylene Chloride |
D
|
100% |
| Milk |
A
|
|
