PTFE 600x600x100 mm natural
P1203072[P1203072] PTFE 600x600x100 mm natural
Material
PTFE
Formato
Lamina
Longitud
600 mm
Anchura
600 mm
Espesor
100 mm
Color
Natural
Egenskaper
Anchura
600 mm
Color
Natural
Espesor
100 mm
Longitud
600 mm
| Material | PTFE |
| Formato | Lamina |
| Longitud | 600 mm |
| Anchura | 600 mm |
| Espesor | 100 mm |
| Color | Natural |
Este contenido se compartirá a través de todas las páginas de productos.
Om produkten
Tekniska specifikationer
Anchura
600 mm
Color
Natural
Espesor
100 mm
Longitud
600 mm
Material
Produktens basmaterial
Fördelar
Aislante eléctrico
Hög volym- och ytresistivitet
Autolubricante
Kräver ingen extern smörjning
Baja absorción de agua
Minimal fuktupptagning, dimensionsstabil
Baja fricción
Låg friktionskoefficient, självsmörjande egenskaper
Resistente a altas temperaturas
Behåller mekaniska egenskaper vid höga temperaturer
Resistente a bajas temperaturas
Behåller mekaniska egenskaper vid låga temperaturer
Resistente a químicos
God motståndskraft mot kemikalier, syror och baser
Certifieringar
EU 10/2011
FDA
REACH
RoHS
Bearbetning
Aserrado
Kapning med såg (band-, cirkelsåg)
Fresado
Bearbetning med fräs
Mecanizado CNC
Datorstödd bearbetning
Taladrado
Håltagning med borr
Torneado
Bearbetning i svarv
| Egenskap | Värde | Enhet | Teststandard |
|---|---|---|---|
| Densidad y peso | |||
| Densidad | 2.1 | g/cm³ | ASTM D1457 |
| Propiedades de tracción | |||
| Límite de resistencia a la tracción | 22 | MPa | ASTM D4894 |
| Módulo de elasticidad (tracción) | 750 | MPa | ISO 527 |
| Resistencia a la tensión | 18 | MPa | ASTM D1457 |
| Deformación a la rotura | 300 | % | ASTM D1457 |
| Propiedades de flexión | |||
| Resistencia a la flexión | 6 | MPa | ISO 178 |
| Resistencia al impacto | |||
| Resistencia al impacto con entalla (Charpy) | 16 | kJ/m² | ISO 179 |
| Dureza | |||
| Dureza Shore D | 58.5 | ° Shore D | ASTM D1706 |
| Dureza a la presión de bala | 45 | MPa | ISO 2039 |
| Límites de temperatura | |||
| Temperatura de servicio máxima (corto plazo) | 260 | °C | |
| Temperatura de funcionamiento máxima | 260 | °C | |
| Temperatura mínima | -200 | °C | |
| Propiedades de aislamiento | |||
| Resistividad volumétrica | 10⁴ | Ω·cm | ASTM D257 |
Identifiering
| Produktnamn | Polytetrafluoreten (PTFE) / Teflon |
|---|---|
| Klassificering | not_classified |
Fysikaliska egenskaper
| Utseende | Fast, ogenomskinlig plast. Vit. |
|---|---|
| Lukt | Lätt, produktspecifik |
| Smältpunkt | 327°C |
| Nedbrytningstemp. | >400 °C |
| Självantändning | >530°C |
| Löslighet | Olöslig i alla kända lösningsmedel |
Beständig
Delvis beständig
Ej beständig
| Kemikalie | Concentración | Beständighet |
|---|---|---|
| 1,4-Dioxane | 100 | |
| 2-Hydroxypropionic Acid | 90 | |
| Acetic Acid | 100 | |
| Acetone | 100 | |
| Ammonia | - | |
| Ammonium Chloride | - | |
| Amyl Alcohol | - | |
| Apple Juice | - | |
| Benzene | - | |
| Bleaching Solution | - | |
| Boric Acid | 100 | |
| Brake Fluid | - | |
| Butyl Acetate | - | |
| Calcium Chloride | - | |
| Carbon Disulfide | 100 | |
| Carbon Tetrachloride | - | |
| Chlorine (gas) | 100 | |
| Chlorobenzene | 100 | |
| Chloroform | - | |
| Citric Acid | 10 | |
| Cresol | - | |
| Cyclohexanone | 100 | |
| Cyclohexene | 100 | |
| Diesel Fuel | - | |
| Diethylene Oxide | - | |
| Ethyl Acetate | 100 | |
| Ethyl Alcohol | 96 | |
| Ethylene Chloride | 100 | |
| Food Oil | - | |
| Formaldehyde (aqueous) | 40 | |
| Formic Acid | 10 | |
| Frost Protection Agent | - | |
| Fuel, aromatic free | - | |
| Glycerine | 100 | |
| Glycol | 100 | |
| Heating Oil | - | |
| Heptane | 100 | |
| Hydrochloric Acid | 10 | |
| Hydrochloric Acid (concentrated) | - | |
| Hydrofluoric Acid | 40 | |
| Hydrogen Peroxide | 10 | |
| Hydrogen Sulfide (aqueous) | - | |
| Isopropyl Alcohol | 100 | |
| Linseed Oil | - | |
| Mercurochrome | - | |
| Methyl Alcohol | 100 | |
| Methyl Ethyl Ketone (MEK) | 100 | |
| Methylene Chloride | 100 | |
| Milk | - | |
| Mineral Oils (aromatic free) | - | |
| Nitric Acid | 10 | |
| Nitric Acid (50%) | 50 | |
| Nitrobenzene | - | |
| Oxalic Acid | - | |
| Ozone Gas | ≤ 0.5 ppm | |
| Paraffine Oil | 100 | |
| Perchloroethylene | - | |
| Petroleum | 100 | |
| Petroleum Ether | 100 | |
| Phenol (aqueous) | ca. 9 | |
| Phosphoric Acid | 50 | |
| Potassium Hydroxide liquor | 50 | |
| Premium Fuel | - | |
| Propyl Alcohol | - | |
| Pyridine | - | |
| Silicone Oil | - | |
| Sodium Carbonate (aqueous) | - | |
| Sodium Chloride (aqueous) | - | |
| Sodium Hydrogen Sulfite | - | |
| Sodium Hydroxide liquor | 15 | |
| Sodium Hydroxide liquor (60) | 60 | |
| Sodium Nitrate (aqueous) | - | |
| Sodium Thiosulfate | - | |
| Sulfuric Acid | 96 | |
| Tetrahydrofuran (THF) | 100 | |
| Toluene | 100 | |
| Transformer Oil | - | |
| Trichloroethylene | 100 | |
| Vinegar (standard) | 5 - 10 | |
| Water | - | |
| Xylene | - |
Especificaciones
| Material | PTFE |
| Formato | Lamina |
| Longitud | 600 mm |
| Anchura | 600 mm |
| Espesor | 100 mm |
| Color | Natural |
